BIOAQUA
Ventilator Compatible Humidifier
Next Generation of ICU Type Humidifier
Bioaqua humidifier is a medical device used in the respiratory tract treatment of critically ill patients. This device performs the functions of humidifying and heating the inhalation gas to prevent damage to the respiratory epithelium from cold and dry medical gases. During invasive, non-invasive mechanical ventilation, and HFO therapy provided by a ventilator, Bioaqua humidifier heats and humidifies the gas in the inspiration line to fulfill this function. Additionally, it offers advanced treatment capabilities with its integrated nebulizer, distinguishing it from other humidifiers.
10-Stage Adjustable
Temperature Values
With a 10-stage temperature adjustment, it provides maximum flexibility during treatment.
Internal Inlet
of the Nebulizer
Thanks to the internal inlet of the nebulizer, it also allows medication during treatment.
Double Line Heating
with Advanced Safety
It has been developed with full safety measures against all possible malfunctions in the heating process.
Visual and
Audible Alarms
Both auditory and visual alarm system offers you convenience in all possible situations.
ICU Type Humidifier (Bioaqua)
Medical instrumentation that is used for treatment in the respiratory tract in critically illpatients prevents the patient from performing inhaledgas humidification and heating functions. Bioaqua humidifier prevents cold and dry medical gases from damaging the respiratory epithelium during invasive and noninvasive mechanical ventilation by heating and humidifying the gas in the inspiration line.
The Most Functional Use of Technology
- The suitable temperature ranges defined for the 3 different modes are as follows:
Invasive Mode: Temperature range of 35°C-40°C
Non-invasive Mode: Temperature range of 30°C-35°C
High Flow Therapy Mode: Temperature range of 30°C-37°C - According to the treatment method, there are 3 different easy temperature adjustment options: invasive, non-invasive, and HFO.
- The integrated nebulizer provides the possibility to administer medication at 3 different speeds for treatment.
- It is suitable for use by all patient groups.
- All alarms are indicated audibly and visually.
- Protection against overheating is provided.
- It can be used with a dual-line heating circuit.
- Due to its ergonomic design, the interface is easily visible and adjustable.
- It is equipped with a control system for patient safety.
- The flow sensor technology detects flow interruption and ensures safety.
- It is suitable for use with ventilators.
Comparison Chart
The table below compares ICU Humidifiers from various brands with the BioAqua (Ventilator Compatible Humidifier). The table is prepared to help you make your decision more easily.
|
A | B | C | |
|---|---|---|---|---|
| Patient Type | Neonatal, Pediatric and Adult | Neonatal, Pediatric and Adult | Neonatal, Pediatric and Adult | Child and Adult |
| Flow Rate | Intubation Mode: 2-60L/m Mask Mode: 2-120L/m |
Intubation Mode: 60L/m Mask Mode: 120L/m |
Intubation Mode: 5L/m Mask Mode: 25L/m |
Intubation Mode: 5-60L/m Mask Mode: 5-120L/m |
| Universal Chamber |
|
|
|
|
| Temperature Setting |
Between 30°C to 40°C + off, 11 different temperature level : Invasive mode: 35 °C- 40°C Non-Invasive mode: 30°C - 35°C HFO mode: 30°C - 37°C |
Invasive mode> Chamber: 35.5 - 42°C, Airway: 35- 40°C Non-invasive> Chamber: 31 - 36°C, Airway 28 - 34°C |
Intubation Mode;
Water Tank: 35.5-420°C By Air: 35-400°C Mask Mode; Water Tank: 31-360°C Airline: 28-340°C |
Test Working Temperature: 18°C ~ 26°C Temperature of inlet gas: 18 °C ~ 26 °C |
| Nebulizer Therapy |
|
|
|
|
| Alarm Parameters |
Low Temperature High Temperature Temperature Probe Not Plugged Breathing Circuit Not Plugged Chamber Not Connected Nebulizer Not Connected Overheat Flow |
Chamber Empty High Temperature Low Temperature Chamber or Airway Probe Probe Connector Heater Wire Operational Alarms |
High-temperature Protection Cut-Off Function |
High Temperature Low Temperature Low Humidity Over-filled Chamber Dry Humidification Chamber Wrong Installation Chamber Lower limit of gas level |
| Has NIV,INV,HFO
and Free Parameter Settings |
|
|
|
|
| Screen |
3.5” touchscreen and control button |
3 digit 14mm 7 segment LED |
2.8” touchscreen | 2.8” TFT and Control Buttons |
| Ergonomic and
Intuitive User Interface |
|
|
|
|
| Warm Up Time | Less than 30 min. | Less than 30 min. | — | Less than 25 min. |
| Shelf Life | 10 Years | 7 Years | No Shelf Life | No Shelf Life |
